Vehicle IR Day/Night Waterproof Exterior Side-view Camera

Model

DR-MSV360036

DR-MSV370136

Pick up Device

1/3” Color SONY CCD

1/3” Color SONY CCD

TV System

PAL/NTSC

PAL/NTSC

Picture Elements

PAL: 728Hx488V
NTSC: 762Hx504V

PAL: 976Hx582V
NTSC: 976Hx494V

Horizontal Resolution

600TVL

700TVL

Sensitivity

0 Lux at F1.2 (Infrared LED On)

Scanning System

625TVL

2:1 Interlace

Synchronization

Internal

Infrared Spectrum

850nm

S/N Ratio

More than 50 dB, (AGC Off)

Auto Gain Control (AGC)

Auto

White Balance

Auto

Electronic Shutter

Auto

Back Light Compensation

Auto

Infrared LED

12 LEDs

Infrared LED Range

10m

Video Output

1 Vp-p, 75Ωcomposite , BNC x1

Audio Output

for Options

Mirror

N/A

Gamma Ratio

0.45

Lens

f3.6mm Standard Lens

Exterior Focus Adjustment

N/A

Lens Mount

M12XP0.5mm Thread

Pan Adjusting

0-360°

Tilt Adjusting

0-40°

Power Supply

12V DC ±10%

Power Consumption

190mA

210mA

Dimensions (L X W X H)

76.4 x 60.5 x 56mm

Net Weight

215g

Weatherproof/Water Proof

IP67

Operating Temperature

-10°C to +50°C
